5
Without the handheld attached to the
reach wand and powered floorhead,
push the wall mount onto the top and
back of the reach wand.
Choose a location for the machine to be
stored. Stand the powered floorhead
and wand against the wall, ensuring the
powered floorhead is flat on the floor.
Holding the wall mount securely against
the wall, make a small mark for each
screw. Secure the wall mount to the
wall using the wall plugs and screws.
The tools can be fitted in to the wall
mount for storage.
Fully assemble the machine and firmly
press the machine into the wall mount
to secure. Always ensure the machine is
securely locked into place.
To assemble align the white arrows. Rotate the dirt container
onto the handheld. Push until it clicks into place.
Attach the handheld to the reach wand until it clicks into place.
Attach the reach wand to the powered floorhead until it clicks
into place.
Assembly
Attaching the wall mount
Getting started
