Machine Overview
2
Accessories
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
Unit
8
3
9
2
1
Handle
2 Upper cord hook (rotating)
3 Lower cord clip (fixed)
4 Power cord
5
Clean water and detergent tank
6 Power button
7 Floor head and compact scrub brush
8 Steam release trigger (hidden)
9 Floor selector buttons
10 Power indicator light
Red light = unit on
11 Steam ready indicator light
Blue light = steam ready
No Green light = water heating to max temp
(NOTE: You can still use your steam mop at
this time)
5
4
1
7
10
11
6
13
12
12 Velcro microfibre cleaning pad
13 Carpet glider / cooling base
14 Vax detergent (qty dependant on model)
15 Hard water filter (hidden - remove clean
water tank (5) to gain access)
16 Coral cleaning pad
17 Pro clean pad
PLEASE NOTE: some parts may vary
according to model. Please check inside
flap of box for more details.
14
16
15
17
