Vax Platinum PowerMax ECB1SPV1 User Manual

Using your machine
Using the hose and tools
NOTE: The carpet washer should be in the upright position when using the hose and tools; this will de-activate
the SpinScrub brushes and brushbar.
Pour the required amount
of carpet cleaning
solution into the tank.
Fill the clean water tank
with warm water
(max 40°C).
Turn the wash/rinse dial
to ‘wash’.
Pull down the accessory
hose connector cover.
Push the hose end and
hose solution connector
into the hose and solution
connection port.
Plug into the mains and
press the On/O button
to switch on.
Select the SpinScrub or Upholstery tool. Slide the tool
over the tab at end of the hose until it clicks into place.
Press the trigger on the hose
to release solution/water.
Squeeze the trigger on the forward stroke and release the trigger
on the backward stroke to pick up water/solution. For a dryer nish,
follow with an additional dry stoke with no trigger pressed.
TIP
Use the carpet washer
or hose to pick up spills
before washing and
cleaning the area.

Vax Platinum PowerMax ECB1SPV1 Specifications

General

Style	Upright
Color	-
Total Power	1200 W
Suction Power	-
Dust Bin Capacity	2.9 L
Power Controls	-
Operating Radius	-
Cord Length	9 m
Hose Length	4.6 m
Automatic Cord Rewind	-
Exhaust Filter	-
Motor Protection Filter	-
Park system	-
?leaning Area	-
Noise Level	-
Cleaning Modes	Spot
Features	Telescopic suction wand
Brushes and Accessories	Dusting brush with synthetic bristles
Power Consumption	-
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	410 mm
Height	1100 mm
Width	340 mm
Net Weight	9.6 kg
