Vax Platinum PowerMax ECB1SPV1 User Manual

Removing and cleaning the brushbar
Taking care of your machine
To ret, loop the brushbar
through the belt and onto
the belt grip.
Line up the ‘right’ side
brushes with base and slide
into place. Attach brushbar
to side brushes.
Pull and slide the right side
brushes together with the
brushbar. Remove the side
cap from the brushbar and
unloop the brushbar from
the belt.
Ret the belt guard and tighten the 2 screws. Replace and
tighten the 4 screws on the side brushes and ret the rug
guards tightening the 4 screws to secure.
Attach the other side
of the brushbar to the side
brushes. Slide onto the side
of the base and into place.
Pull and slide the left side
brushes and remove the
side cap from the brushbar.
Using a crosshead screwdriver remove the 4 screws
on the side brushes and the top and bottom screws
from each of the rug guards (metal pins) to get access
to the brushbar.
Using a crosshead
screwdriver, undo the 2
screws and remove the
belt guard.
Using a pair of scissors,
remove any threads or hair
caught around the brushes.
Rinse under water to
remove debris.

Vax Platinum PowerMax ECB1SPV1 Specifications

General

Style	Upright
Color	-
Total Power	1200 W
Suction Power	-
Dust Bin Capacity	2.9 L
Power Controls	-
Operating Radius	-
Cord Length	9 m
Hose Length	4.6 m
Automatic Cord Rewind	-
Exhaust Filter	-
Motor Protection Filter	-
Park system	-
?leaning Area	-
Noise Level	-
Cleaning Modes	Spot
Features	Telescopic suction wand
Brushes and Accessories	Dusting brush with synthetic bristles
Power Consumption	-
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	410 mm
Height	1100 mm
Width	340 mm
Net Weight	9.6 kg
