Machine Overview
1 Handle
2 Dirt container lid
3
HEPA filter
4 Dirt container
5 Lower hose inspection tube
6
On/off switch
7 Brushbar height adjuster
8 Vacuum head
9 Wheel
10 Cord safe hook
11 Dirt container release button
12 Crevice tool (stored in extension tube)
13 Extension tube
14 Hose clip
15 Hose
16 Power cord
17 Hose connector
18 Lower cord wrap with quick release
19 Handle release pedal
20 Two (2) short screws
21 Two (2) long screws
22 TurboTool (Some models only)
9
12
19
18
20
2
1
22
WARNING: This cleaner has a constantly rotating brushbar which,
when left in contact with lino, parquet and other hard flooring could
potentially cause some damage to the floor surface.
NOTE: Vax recommends that you raise the height of the brushbar
when using this cleaner on lino and hard flooring. Vax cannot be held
responsible for damage to these surfaces if the customer fails to take
notice of this recommendation.
PLEASE NOTE: Some parts may vary
according to model. Please check inside
flap of the box for more details.
