Operation
Installing side brushes for use in sweeping mode
To install
Push the brush directly onto the holder until
it snaps into position.
To remove or replace
Hold the brush and pull upward to remove the brush
as shown.
Adjustment of cli sensors
If the distance between the stair and the ground is short, please adjust both windows of “cli ” sensors (A)
to “2” or “1” or “0” position to prevent the cleaner from falling down stairs. Please test it before working.
ATTENTION: If the colour of the oor is dark (e.g. Black), and robot goes backwards continuously, close the
window position to the “1” to increase the cli sensor’s sensitivity (C) position.
BOTTOM
A
A
A
1 2 30
1 2 30
1 2 30
1 2 30
B
C
Cli sensors prevent the robotic sweeper from falling o stairs and ledges. There are 3 sensors located on the
underside of the robotic sweeper.
WARNING: to reduce the risk of injury from moving parts – turn power o (0=o ) and unplug charger
before adjusting.
WARNING: to reduce the risk of injury from moving parts – turn power o (0=o ) and unplug charger
before installation and removal/replacement.
