Vax W85-PL-T Dual Power Pro Advance

Let’s talk technical
Changing the brushbar (continued)
Undo the four screws on the side brushes.
Pull and slide right side brushes together with brushbar.
Remove side cap from brushbar and unloop brushbar
from belt.
Line up the ‘right’ side brushes with base and slide
into place. Attach brushbar to side brushes.
Ret belt guard and tighten x2 screws. Ret and tighten screws x2
on either side of side brushes. Ret SpinScrub brushes.
Ret the rugguards and tighten screws.
Attach the other side
of brushbar to side brushes.
Slide onto side of base
and into place.
Loop replacement brushbar through belt
and onto belt grip.
Pull and slide left side brushes and remove side cap
from brushbar.
Always unplug the carpet
washer before performing
any maintenance/
troubleshooting checks.
CAUTION
