Vax X5 - Assembly

ASSEMBLY
6
TOOL REQUIRED: PHILLIPS OR FLATHEAD SCREWDRIVER
Using a Phillips or Flat Head screwdriver,
secure the handle by inserting the
provided four screws into the back of
the handle.
4.
Align handle onto base of cleaner.
3.
Pull cleaning wand to the front
of the cleaner and press hose
into handle assembly.
Insert excess cord into handle of the
cleaner by pushing down into lower
handle. CAUTION: AVOID PINCHING
CORD WHILE INSERTING INTO
HANDLE.
Connect the cleaning wand to
the opening on the base and push
the wand handle towards unit
until it snaps into place.
1. 2.
5.
Use carry handle located on dirt
container lid.
1.
TRANSPORTING
YOUR CLEANER
NOTE: Do not
carry vacuum
cleaner by the
cleaning wand
tube.This is not
a carry handle.
