Reset system
1. Switch the ignition off and on again.
Alternatively
Remove the fuse (7.5 A) from the fuse box. This is located in the dashboard or under the driver's
seat.
Service
1. The SERVICE button has only one function:
Switching service mode on and off.
Note:
Does the vehicle have a tailgate and/or jacks? Remember: If any of these systems are active
at the same time as the air suspension system, the air suspension system must be
switched off using the SERVICE button.
Switch service mode on and off
1. Press once
The button is lit continuously.
Service mode can be used to switch off the system in order to carry out work on the air
suspension or read out possible faults. To guarantee total safety, we recommend you remove
the fuses from the air suspension system.
7.5 A fuse – for the controller
40 A fuse – for the compressor
“With the ‘emergency valve kit’ option, the air suspension system can be pressurised at any time (see
page 22).”
