FC 3500 DC Fan Control
Document no.:150304 Version: 1.2
Page 9 of 23
3 Technical Data
FC 3500 DC Description Comment
Power supply voltage
Power consumption
On/Off switch before
FC 3500 DC
Electronics fuse
J1:
90Vac .. 260Vac, 50/60Hz
34,5 VA
1,5mm2 (14 AWG) flexible or
solid wirring stripped 9mm.
F1: 315 mA / 250Vac Slow
Supply
(L, N, PE)
Water valve output
Internal fuse F2
J20:
Triac output 90Vac .. 260Vac
50/60Hz, Max. 1A
F2: 1 Amp./250Vac Slow
Valve (Lout, N, PE)
Alarm relay output
J5:
SPDT contact, max.
8A/250Vac or 5A/30Vdc
Relay (NO, NC, C)
Dimensions
FC 3500 DC Fan Control
FC 3500 BP Display unit
247 x 145 x 63,5mm
102 x 102 x 44mm
Temperature ranges
Set point
Air Sensor
Water sensor
+9/+29°C (+48/+85°F)
-20/+100°C [-4/+212°F)
-20/+100°C [-4/+212°F)
Default settings
See parameter list
Temperature
s
ensors
J9:
Air
-
sensor /
2,2m
J10: Water-sensor / 2,2m
J11: Outside-sensor / 2,2m
(2
-
wire 10K NTC)
(2-wire 10K NTC)
(2-wire 10K NTC)
Contact input
J19:
Dig_in potential free
contact-input
(
NO, Gnd
)
Optional 3
-
wire sensor1
Jumper U/I
J12:
Optional sensor1 U or I
J30: Selection U or I input
(+12Vdc, Signal, 0V)
0-1V, 0-10V or 4-20mA
Optional 3
-
wire sensor2
Jumper U/I
J13:
Optional sensor1 U or I
J31: Selection U or I input
(+12Vdc, Signal, 0V)
0-1V, 0-10V or 4-20mA
Analog output
J14:
U or I output selected by load
Rload>1K = Voltage out,
50E<Rload<400E = Current out
(Signal, Gnd)
Fan outputs
J15:
Fan1 output 3
-
wire
J16: Fan2 output 3-wire
J17: Fan3 output 3-wire
J18: Fan4 output 3-wire
(FB, Gnd, Signal 0
-
10V=)
(FB, Gnd, Signal 0-10V=)
(FB, Gnd, Signal 0-10V=)
(FB, Gnd, Signal 0-10V=)
On/off control outputs
J2:
Valve, Heat and Fan(s) outputs
Valve output
Heat output
Fan(s) output
(12Vdc out max. 100mA)
(12Vdc out max. 100mA)
(12Vdc out max. 100mA)
Communications
J6:
RS485 with supply for display
J3: Ethernet (to network)
(+12V, A, B, Gnd)
Operation temperature
Storage temperature
Operation humidity
0/+40°C (non
-
freezing)
-20/+65°C
90%RH or less (non-condensing)
Ambience
Indoors in a ventilated area
(see also operation temp./humidity))
(free from
corrosive gas,
flammable gas, oil, mist,
dust, dirt and water)
