13. User defined output resolution
13.1. When select 1.2 Resolution rotate OK to select Custom 1920 x 1080_60,
then press OK to enter custom resolution configuration menu;
13.2. press Brt- or Brt+ key to select setup option , rotate OK to change
parameters, after configuring custom resolution parameters select 1.1.4
Apply then press OK to save parameters;
the conditions of resolution customization：
1 the biggest width must be less than 3840，the biggest height must
be less than 1920;
2 custom V FREQ between 23—80Hz，normally use 60Hz；
2. Output Image
--------------------------------------------------------------------
1.2 Resolution Custom 1920 x 1080_60
1.2 Out Width 1920
1.3 Out Height 1080
1.4 Out H_Start 0
1.5 Out V_Start 0
1.6 Test Pattern Off
1.1 Custom Resolution
--------------------------------------------------------------------
1.1.1 Cus. Width 1920
1.1.2 Cus. Height 1080
1.1.3 Cus. V freq. 60
1.1.4 Apply OK To Apply
