VEAB EA Series - Specification; Maintenance

Specication
Type EA 6 EA 9 EA 14 EA 21 EA 30
Rated voltage 400V3N~ 50Hz 400V3N~ 50Hz 400V3N~ 50Hz 400V3N~ 50Hz 400V3N~ 50Hz
Rated power 6 kW 9 kW 14 kW 21 kW 30 kW
Reduced power 3 kW 6 kW 7 kW 14 kW 20 kW
Rated current 8,7 A 13,0 A 20,3 A 30,4 A 43,5 A
A 157 mm 157 mm 220 mm 220 mm 220 mm
B 425 mm 425 mm 600 mm 600 mm 600 mm
W 390 mm 390 mm 555 mm 555 mm 555 mm
H 450 mm 450 mm 600 mm 600 mm 600 mm
D 270 mm 270 mm 375 mm 375 mm 465 mm
Master EA heater #1 slave EA heater 1 #2 slave EA heater # n slave
12
EA
Slave controlling several heaters
One EA heater can slave control several other EA heaters. e Master EA can be controlled either by the
OCC4/OCD4, TG-R430 or by a 0...10VDC (2...10VDC) excitation voltage. e slave heaters are cascaded
by the 0...10VDC voltage and the excitation cable length, from one heater to another, must not exceed 16m.
1. e EA heater series are approved for fixed installation in dry, damp or wet rooms but not in
environments where there is risk for fire or explosion.
2. e heater must be connected to the mains supply with a fixed installed round cable,
which ensures that the electrical protection class of the heater is retained.
3. An all phase breaker with a contact gap of at least 3mm must be included in the fixed installation.
4. e installation must be carried out by an authorized electrician.
5. e heater is S-marked, CE-marked, EMC-marked and designed in accordance with the following standards
EN 60335-1 / EN 60335-2-30 / EN 61000-6-4 / EN 61000-6-1 / EN 61000-6-2 / EN 61000-6-3.
6. e heater must not be located immediately below a socket outlet.
Mounting
1. e heater brackets are to be fastened to the wall or to the ceiling with screws.
e distances shown in the above sketch are minimum. Distances less then shown may cause fire.
2. e connection box must always be positioned upwards.
3. e heater must not be covered or tampered with, to avoid overheating, fire or electric shock.
Maintenance
No maintenance is required except a periodic functional test and cleaning.
Overheatig
e heater is thermally protected by an overheat cut-out with manual reset, with the the reset button placed
on the lid of the connection box.
