Vechline 1012 - Technical Specifications; Disclaimer

3
The radix point of
digital tube fast
flashing and load not
working
Short circuit
Clear short circuit. It is reactivated after delayed 10
seconds for the first time, If over 1 time，press the key
to clear error and the controller will resume to work
after 3s or restart the controller
The radix point of
digital tube slowly
flashing and load not
working
Over load
Please reduce the number of electric equipments.
When load power reaches 1.25-1.5 times, 1.5-2 times
and 2 times more than nominal value, controller will
automatically close loads in 60 seconds, 5 seconds
and 1 second, respectively. Please press the key to
clear error and the controller will resume to work after
3s or restart the controller
5. TECHNICAL SPECIFICATIONS
Item
1012
2024
Nominal system voltage
12/24VDC Auto
12/24VDC Auto
Max. PV input voltage
50V
50V
Rated current
10A
20A
Equalize Voltage
14.8V(12V);29.6V(24V)
Boost Voltage
14.4V(12V);28.8V(24V)
Float Voltage
13.7V(12V);27.4V(24V)
Low Voltage Reconnect Voltage
12.6V(12V);25.2V(24V)
Low Voltage Disconnect Voltage
11.2V(12V);22.4V(24V)
Self-consumption
12V：≤4.58mA；24V：≤6.01mA
Temperature compensation
coefficient
-5mV/℃/2V（25℃）
Working temperature
-35℃～+50℃
Enclosure
IP67
Overall dimension
108.5mm×75mm×25.6mm
Mounting dimension
100.5mm
Mounting hole size
Φ5
Power cable
PV/BAT/LOAD:4.0mm
2
PV/BAT/LOAD:6.0mm
2
Net weight
410g
435g
6. DISCLAIMER
This warranty does notapplyunderthefollowingconditions:
Damagefromimproperuse or use in anunsuitable environment.PV or load current, voltage or power
exceedingtheratedvalue of controller.The controller’ s workingtemperatureexceedthe limit working
environment temperature.User disassembly or attemptedrepairthe controller without permission.The
controller is damagedduetonaturalelementssuch as lighting.The controller is damagedduring
transportation and shipment.
Vechline is powered by
OCS-RECREATIE GROOTHANDEL BV
Tel: +31-(0)74 2455680
E-mail：info@ocs-recreatie.nl
Website: www.ocs-recreatie.nl
