PI Control Sequence
Parameter
Description
Range
Default
1L 09
P – band heating X
PH
0…100 °C
2.0 °C
(4.0 °F)
1L 10
P – band cooling X
PC
0…100 °C
2.0 °C
(4.0 °F)
1L 11
K
IH
, integral gain heating, in 0.1 steps, 0 disables I part
0…25.5
0.0
1L 12
K
IC
, integral gain cooling, in 0.1 steps, 0 disables I part
0…25.5
0.0
1L 13
T
I
interval time speed: OFF = seconds, ON = minutes
ON, OFF
OFF (sec)
1L 14
T
I
, measuring interval integral
0…255
1 sec
1L 15
Delay heat / cool change over
0…255 min
5 min
Control parameters analog input
Parameter
Description
Range
Default
2L 00
Standby set point shift
Acc. input
0%
2L 01
Minimum set point limit for reverse
Acc. input
0%
2L 02
Maximum set point limit for reverse
Acc. input
100%
2L 03
Minimum set point limit for direct
Acc. input
0%
2L 04
Maximum set point limit for direct
Acc. input
100%
2L 05
Dead zone between reverse & direct set point X
DZ
Acc. input
0%
2L 06
Cascade control: set point provided by primary loop (loop 1),
loop 2 is secondary loop)
0 = no cascade control
1 = cascade control with loop 1 on reverse only
2 = cascade control with loop 1 on direct only
3 = cascade control with loop 1 reverse and direct
0…3
0
2L 07
Summer – winter compensation
0 = disabled
1 = winter compensation only
2 = summer compensation only
3 = winter and summer compensation
0…3
0
2L 08
Direct / reverse related to heat / cool setting
OFF = not related
ON = related
ON, OFF
OFF
PI Control sequence
Parameter
Description
Range
Default
2L 09
P – band reverse X
PH
Acc. input
10%
2L 10
P – band direct X
PC
Acc. input
10%
2L 11
K
IR
, integral gain reverse seq., in 0.1 steps, 0 disables I part
0…25.5
0.0
2L 12
K
ID
, integral gain direct sequence, in 0.1 steps, 0 disables I part
0…25.5
0.0
2L 13
T
I
interval time speed: OFF = seconds, ON = minutes
ON, OFF
OFF (sec)
2L 14
T
I
, measuring interval integral
0…255
1 sec
