Installation Guide National Electrical Code Compliance
7
Equipment Dimensions
Dimensions of the TLS RF are shown in Figure 3.
0.34''
(8,6 mm) typ.
7.4"
(188 mm)
6.4''
(163 mm)
5.7''
(145 mm)
2" (51 mm)
5.3''
(135 mm)
consoles\tlsrf\fig3.eps
0.22'' (5,6 mm) dia.
3.75"
(95mm)
0.4''
(10 mm)
0.93''
(23,6 mm)
0.93''
(24 mm)
1.25''
(32 mm)
0.93''
(23,6 mm)
2.6''
(66)
0.7''
(17,8)
0.93''
(24 mm)
6.7"
(170 mm)
1.18''
(30 mm)
1
1
2
1
2
Figure 3. TLS RF dimensions and designated conduit knockouts
LEGEND FOR NUMBERED BOXES IN FIGURE 3
1. Designated power wiring knockouts. 2. Designated intrinsically-safe wiring knockouts.
