POS App Guide DIM Installation Examples
33
Figure 14. Tokheim Dispenser Controller With Single CAB Installation
401-19.eps
ALARM
WARNING
POWER
T1: PREMIUM UNLEADED
VOLUME
ULLAGE
90% ULLAGE
TC VOLUME
HEIGHT
WATER VOL
WATER
TEMP
T1: REGULAR GASOLINE
VOLUME
ULLAGE
90% ULLAGE
TC VOLUME
HEIGHT
WATER VOL
WATER
TEMP
4208 GALS
5792 GALS
4792 GALS
4194 GALS
41.02 INCHES
0 GALS
0.00 INCHES
65.0 DEG F
9038 GALS
962 GALS
0 GALS
8950 GALS
81.37 INCHES
28 GALS
1.37 INCHES
74.9 DEG F
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
Cable connects
to J7 or J8
on rear panel
CAB
RJ-45
RJ-45
Dispenser Controller
Dispenser Interface Box
Tokheim 67A
Tokheim 67B
Tokheim 98
DB9
Barrel
Connectors
DB9
Barrel
Connectors
P/N: 330902-XXX
- P/N 331394-001 (for Tokheim 67A or 98)
- P/N 331394-002 (for Tokheim 67B)
Cable 331392-001 Cable 331393-001
Connects to
CDIM
Break Connection
TLS-350R Console
