4. CHARGE / CONNECT ADAPTER
CHARGING CONNECTOR
BATTERY CONNECTOR
BATTERY PLUG
3
1
2
1. Disconnect the battery connector
(right) from the battery connection
port (1) and install it to the left for it
free space (2). Connect the adapter
the round charging port which is abo-
ve the battery connection point is
located (3).
2. Connect the plug of the adapter then
with a socket of 220V.
3. While the scooter is charging,
the charger light is on red.
4. The light of the charger green when
the scooter is almost complete is char-
ged. After the light turns green we ad-
vise to continue for 1 to 1.5 hours to
recharge the battery full load.
5. Remove the plug after charging socket
and disconnect the plug van de Veeley,
then close the battery plug back on
[2 in 1] and close the cover.
NOTE: Do not leave the charger connected to the Veeley as the battery is fully
charged, but then disconnect it.
NOTE: It is for safety reasons that the battery must be disconnected rst be
able to charge before.
