5. TAKE INTO OPERATION
4. Extend the support rod to the cor-
rect height and secure it. (D)
D
5. Then place the saddle in the correct
position on top of the support rod
and slide the support rod into
the holder under the saddle and
straighten it.
6. Secure the saddle with the rotary
knob which is located under
the saddle.
Folding back the saddle is done in the reverse order:
1. Loosen the rotary knob
2. Loosen the saddle of the support rod
3. Fold up the saddle post and the locking mechanism of the at saddle bar
(if applicable, depending on the selected saddle height) again forward slide
4. Shorten the support rod
5. Fold the support rod down and push it into the footboard
6. Then fold the seat post back into the footboard and the lock lever push down
7. Fold down the seat and secure it
