Owner’s Manual
DESCRIPTION
THE CAVALIER
Choice of colors
Red / Titanium / Black
1. 48V/500W Super High Torque brushless motor
2. Alloy frame
3. Battery A – Lithium 48V/11Ah or 48V/14Ah or 48V/17Ah
Battery B - Lithium 48V/4,4Ah (Optional)
4. Throttle
5. LCD Control Panel
• -/O
• 5 Assistance mode (0 and 1 to 5)
• Cruise Control
• Battery Level
• Odometer
• Distance
6. Double wall 26 inches wheels
7. Kenda tires 26 x 1,95 with K-Shield Protection
8. Single rear carrier
9. Shimano Acera derailer 8 speed
10. Cassette 11/32T
11. 48T Chain-wheel
12. Shimano disc brake front and rear wheels
13. Alloy stem
14. Front fork suspension
15. Seat post suspension 30,4mm
16. Alloy front and rear fenders
17. Front LED light driven by main battery
18. Rear LED light (2 - AA battery)
19. Bicycle weight (without battery) 21 kg or 47 lbs.
20. Battery weight 4 kg or 9 lbs.
* May differ from photograph
Specifications could change without warning.
Speed & Distance (Under ideal conditions*): Potential Speed up to 32 km/h or 20 mp/h
Range:
No Pedalling Mode: 40 km to 62 km or 25 miles to 39 miles per battery depending on
battery choice, with a complete charge and in ideal conditions.
Level 2 Pedal Assist Mode: 75 km to 120 km or 47 miles to 75 miles per battery
depending on battery choice, with a complete charge and in ideal conditions.
*Ideal conditions: These apply for an 85kg or 187 lbs. person riding on paved and level roads,
without headwinds, and with tires inflated to manufacturer’s specifications (see recom-
mended pressure on side of tire), and at 20 km/h or 13 mp/h.
VELEC
R48P48V
1
10
9
11
7
17
6
16
12
5
15
4
8
16
18
3
2
13
14
