Owner’s Manual
48V
MODELS R48M/48V
First, make sure that the battery locked within the frame.
To activate the R48M, press -/O on the right side of the battery and -/O on
the left side of the handlebar. The LCD panel will show Assistance mode 0.
In order to use the assistance or the throttle, select the assistance level
between, 1 to 5 on the LCD panel.
If you shutdown the bicycle with the -/O on the left side of handlebar or
on the battery, the assistance Level will return to 0 when you reactivate for
security purpose.
Batterie -/O
Button on handlebar
LCD Panel with the assistance
mode 0
There are 4 lights on the top of the battery next to the red Button. The first
light is red and will glow only if the battery is discharged; the other 3 lights
are green and indicate the charge level: 3 lights lit indicate an approximate
100% charge; 2 lights lit indicate a level of charge of about 55%; only one
light glowing indicates a charge level of approximately 25%.
The battery’s charge level is visible on the Control Panel.
Battery Charge Level on
LCD Control Panel
Battery Level
Assistance Level
Buttons
