62
63
Owner’s Manual
THE ELITE
Choice of colors
Red / Titanium / Black
VELEC
R48M48V
* May differ from photograph
1
10
9
11
7
17
6
16
12
5
14
9
8
16
18
3
2
15
13
48V
DESCRIPTION
Specifications could change without warning.
Speed & Distance (Under ideal conditions*): Potential Speed up to 32 km/h
Range:
No Pedalling Mode: 40 km to 55 km or 25 miles to 35 miles per battery depending on
battery choice, with a complete charge and in ideal conditions.
Level 2 Pedal Assist Mode: 90 km to 120 km 55 miles to 75 miles per battery depending
on battery choice, with a complete charge and in ideal conditions.
*Ideal conditions: These apply for an 85kg or 187 lbs. person riding on paved and level roads,
without headwinds, and with tires inflated to manufacturer’s specifications (see recommended
pressure on side of tire), and at 20 km/h or 13 mp/h.
1. 48V/350W SHT mid-drive motor
2. New generation alloy frame
3. Battery A – Lithium 48V/11Ah or 14Ah
4. Battery B – 48V/7Ah (Optional)
5. Throttle
6. Control Panel (Optional LED Panel)
a. -/O
b. 5 Assistance mode (0 and 1 to 5)
c. Battery Level
d. Cruise Control
7. Double wall 26 inches wheels
8. Schwalbe Marathon Plus 26 x 2,00 tires
9. Single rear carrier
10. NuVinci E380/C3 HUB - 8 speed
11. Gates Carbon fiber belt
12. Front and rear Shimano disc brake with cut-off motor
13. Front fork suspension
14. Seat post suspension 30,4mm
15. Alloy adjustable stem
16. Alloy front and rear fenders
17. Front LED light driven by main battery
18. Rear LED light (2 - AA battery)
19. Bicycle weight (without battery) 21 kg or 47 lbs.
20. Battery A weight : 4 kg or 9 lbs.
21. Battery B weight : 3 kg or 6 lbs.
