DCM269/DCM270 VELLEMAN
DCM269/DCM270 – MINI AC/DC CLAMP METER
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialised
company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying the DCM269/DCM270! Read the manual carefully before bringing this device into service.
2. Features
• 3 2/3- digit (2400 counts) LCD display with white LED backlight
• 18mm (0.7") jaw opening
• 0.1-200A current measurement
• built-in non-contact AC voltage detector
• incorporated flashlight
• frequency measurement 40Hz-1kHz
• autoranging with auto power off
• data-hold function
• overload protection for all ranges
• overrange and low battery indication
• supplied with pouch
3. Specifications
General Specifications
Display 3 2/3 digit LCD (2400 count) with white LED backlight
Polarity "-" indicates negative polarity
Overload Indication "OL" is displayed on the LCD
DCA Resetting Adjustment one-touch "zero" key
Display Rate 2 readings/sec., nominal
Battery 2 x 1.5V AAA-batteries
Low-Battery Indication "BATT"
Auto OFF ± 7 minutes
Temperature Range 0 to +30°C (32 to 86°F), 90% RH
30 to 40°C (86 to 104°F), 75% RH
40 to 50°C (104 to 122°F), 45% RH
Storage Temperature -30 to +60°C (-14 to 140°F), < 90% RH
Altitude < 3000m
Weight 175g with battery
Dimensions 164 x 65 x 32mm (H x W x D)
Jaw Opening 18mm
Standards IEC 1010 Category II 600V
