Velleman K4001 User Manual

9
Connection example
Figure 3.0 is an example of a connection diagram of a 4 or 8 ohm speaker that is connected to the pins LS
and GND. The input signal should be connected with the IN and GND pins.
9. Connection example
4/8 OHM SPEAKER
+
-
8..18VDC / 0.5A
47K LOG POTENTIOMETER
+
-
-
+
FROM AUDIO SOURCE
Fig. 3.0

Velleman K4001 Specifications

General

Impedance	150000 Ω
Sensitivity	86 dB
Amplifier class	-
Frequency range	20 - 20000 Hz
RMS rated power	3.5 W
Audio output channels	- channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.05 %
RMS power output per channel (8 Ohm)	2 W
Output power	7 W
Power requirements	15VDC, 0.5A
Connectivity technology	Wired
Product color	Green
Handheld remote control	No
Manual	Yes
Maximum current	0.5 A
DC input voltage	8 - 18 V

Weight and Dimensions

Depth	35 mm
Width	55 mm
