Velleman MA620B - Technical Specifications

MA620B VELLEMAN
2
TECHNICAL SPECIFICATIONS
Min. operating voltage 9VDC
Max. operating voltage 15VDC
Power consumption
arm/disarm
stand-by
alarm
70mA
6mA
140mA
Operating temperature -35°C to +85°C
Relay output (ignition cut-off) 15A/120VAC
Operating humidity 110% non condensing
Operating range 16 - 40 meter
Transmitter battery replacement GP23GA, V23GA
Alarm cycle 30 seconds
Passive rearming timer 15 seconds
Self learning code system 118098 codes sequences
472392 different codes
Output sound level 110dB à 1 meter
Impact sensor fully electronic piezo shock
sensor
Vibration 6G repetitive
Alarm delay 3 seconds
Emitter frequency 433.92MHz
Wiring harness 1.5 meter
Flashing light output 10 A
Main fuse (red wire) 3 A
Dimensions 100x60x25mm
