MA620B VELLEMAN
7
Press button II to enter choosing shock sensitivity. By pressing button II again you can scroll
through 8 levels and 8 different chirps. The less chirps the more sensitivity the alarm is to
shock. 1 chirps is the maximum sensitivity, 7 chirps is the minimum sensitivity, 8 chirps is
delete shock sensor.
TEST SENSITIVITY :
1. At any time, you can stop an try out the sensitivity by dragging pulling tugging on hitting
your motorcycle. The alarm should trigger.
2. To avoid false alarm, please do not set the alarm over sensitivity. Adjust lesser sensitivity
that also protect your motorcycle well.
EXIT PROGRAMMING MODE :
Turn ignition switch on-off to exit programming mode. Or during shock sensor programming
press button I to exit.
WIRING
OPERATION MANUAL
Blue Wire : To LED
White/Black Wire : To Siren Output
White Wire : Parking Light
Red/White Wire : To Fuse Box
White Wire : Parking Light
Red Wire : To Constant + 12V
Gray Wire : To Valet Switch
Black Wire : To Ground
Yellow Wire : To Ignition Coil
Yellow Wire : To Ignition Switch Input
Green Wire (Ground Trigger) : To optional Sensor
Motorcycle
Battery
2A Fuse
10A Fuse
Right
Left
+12V
Cut
Black
Red
Black
