MA620B VELLEMAN
8
A. TRANSMITTER OPERATION :
Transmitter Button System Function Remark
Button I Arm / Disarm
Button I - I Armed And Delete Shock Sensor Press 2 Times Within 3 Seconds
Button I Panic Press And Hold For 3 Seconds
Button II - I Silent Arm / Disarm
Button II Motorcycle Locator Press And Hold For 2 Seconds
Button II - II Valet Mode Press 2 Times Within 3 Seconds
B. LED INDICATORS :
LED Function
Off Disarmed
Slow flashing Armed
Fast flashing Passive arming
1 flash …… pause Intrusion on ignition circuit
2 flashes … pause Intrusion on optional sensor
3 flashes … pause Intrusion on shock sensor
C. CHIRP INDICATORS :
Chirp Function
1 chirp Arm
2 chirps Disarm
3 chirps Temporary valet mode
4 chirps Disarm / Intrusion
D. PARKING LIGHT :
Parking light Function
1 flash Arm
2 flashes Disarm
3 flashes Disarm / Intrusion
E. VALET/OVERRIDE FUNCTION :
1. OVERRIDE FUNCTION :
The override/valet switch is used in case of an emergency, such as a lost or malfunction of the
transmitter, you can still disarm the system. First turn the ignition switch on, within 15
seconds turn 'on' and 'off' the override/valet switch, the siren will stop and the system will be
disarmed.
2. VALET MODE
If the motorcycle is in service, the valet mode feature allows the user to by-pass the alarm
system's function. The system will not armed itself.
Enter : Turn the ignition switch 'on' then within 15 seconds turn valet switch to 'on' position,
the red LED will turn solid 'on' to indicate the system is in 'valet mode'. You will
hear 3 chirps from siren.
Exit : Turn the ignition switch to 'on' position then turn the valet switch to 'off' position. The
system will exit valet mode.
F. PASSIVE ARMING :
This system is equipped with a passive arming circuit. It operate as below :
