4. Rotate the battery tray
lever counterclockwise
and slide the battery tray
all the way into the grip.
Rotate the lever clockwise
and push it back into place
to lock the tray.
5. Switch the grip control-
lock to ON and then turn
on the camera’s power.
Check the battery level
in the control panel or
viewfinder.
6. Household Power Outlet:
The Canon ACK-E6
AC Power Adapter Kit
(sold separately) can be
connected to the grip.
Place the DC coupler
through the small groove
on the back of the grip.
Ensure that the cord
doesn’t get pinched by the
battery holder.
Make sure the camera's power
switch is in the Off position
before mounting the DC
coupler.
9
