Vello shutterboss II User Manual

TIMER CONTROLS
SHUTTER CONTROLS
CH
BATT

. Turn on the receiver by pressing and
holding the Power button until the display
comes on.
2. Set your camera to single shot mode.
3. Use the arrow button on the transmitter
to select single shot mode. Press
the left and right arrows until the
single shot icon is displayed in the
bottom left of the screen.
4. Press the transmitter’s shutter release
button halfway to wake or focus your
camera (if set to Auto Focus). The LEDs
on the transmitter and receiver will both
turn green.
5. Fully depress the shutter release button
on the transmitter. The LEDs will turn red
and the shutter will be triggered.
SHUTTER CONTROL: SINGLE SHOT
In single shot mode, only the single shot
icon and the channel in use will display.

Vello shutterboss II Specifications

General

Supported Cameras	(See enclosed insert)
Exposure Range	0s to 99hr 59min 59s in one-second increments
Number of Shots	1-999 or ∞
Frequency	99 selectable channels over FSK 2.4 GHz
Range	250 feet (80 meters)
Timer Control: Delay	0s to 99hr 59min 59s in one-second increments
Interval	1s to 99hr 59min 59s in one-second increments
Operating Temperature	−4° to +122°F (−20° to +50°C)

Weight and Dimensions

Dimensions (Transmitter)	5.9" × 2" × 1" (149 × 50 × 24 mm)
Dimensions (Receiver)	2.5" × 1.5" × 1.2" (63 × 38 × 31 mm)
