How to Charge Your Bike
There are two ways to charge your battery.
1. Charge the battery ON the bike
1) Find the Charge Port at the bottom of the downtube.
2) Pull out the cover to show the charge port and insert the charger output plug into the port.
Connect the input plug to the power supply.
2. Charge the battery OFF the bike
1) Take off the battery from your bike.
2) Place the battery in a clean and flat place in room temperature.
3) Insert the charger output plug into the charge port. Connect the input plug to the power supply.
4) There is a capacity indicator at the top of the battery. Press the button beside to check the
charge status. Green means sufficient of charge. Yellow means less than 30%. Red means
less than 10%.
