PREPARE THE CHARGER INSTALLATION
1. Mark the holes to be made.
2. Drill the holes.
3. Fit the wall plugs.
Insert the screw of the upper part and tighten it into the bushing as far as it will go.
In the case of the STAND, use the screws supplied with it in the packaging.
8
FIT THE UPPER SCREW
8 mm
1
2
3
Wall mounting: 4.8x38 screw
STAND assembly: M5x12 screw
