INSTALLATION
Connect the electric terminals of the power cable to the corresponding points on the
charger.
Make sure that all screws are securely tightened for eective contact of the
conductor’s active elements.
9
CONNECT THE CHARGER
Neutral
Phase 1
Phase 2
Phase 3
Ground
Neutral
Phase 1
Ground
LITE Zero/Uno LITE Kubo
• OPTIONAL: If you are also going to install a CURVE device, connect the wiring from
that device. For more information, see “INSTALLATION OF THE CURVE DEVICE”.
• OPTIONAL: If you are going to connect the charger to a three-phase energy meter,
a communications device (modem, router, switch, ...) or to another charger, check
that the Ethernet wiring from that device is also available. For more information,
see “INSTALLATION OF THE THREE-PHASE METER SET” and/or “CONNECTION OF
THE CHARGER TO ANOTHER CHARGER, OR TO A COMMUNICATIONS ELEMENT”.
