INSTALLATION
MANUAL
1. Fit the three screws on the lower part of the charger and tighten them rmly.
2. Fit the caps to cover the three screws.
13
FIX THE CHARGER TO THE WALL
14
INSTALL THE CHARGING CABLE SUPPORT
1. Mark the holes to be made in the wall.
2. Drill the holes.
3. Fit the wall plugs.
8 mm
1
2
3
Wall mounting: 4.8x90 screw
STAND assembly: M5x70 screw
1
2
3- INSTALLATION
