2 VELUX
®
VAS 454612-2020-01
RESET
Press and hold
10 sec
454612-2020-01_KLC 410 label.indd 1
06-01-2020 08:54:14
Position control unit KLC410 on the wall inside the house (eg next to the consumer unit).
NOTE: When extending the cable (up to max. 20 m) between control unit KLC 410 and chain actuator
WMU/roller blind RMM, the cable dimensions in the table must be observed.
You can connect max one motor wire to one control unit KLC 410.
Control unit KLC 410 works for both single and dual actuated rooflights.
mm
2
2 x 0.75 2 x 1.50
RMM 2 x RMM 4 x RMM
WMU 2 x WMU
KLC 410
RMM
WMU
20 m
