10 EN
PUTTING INTO OPERATION
!
Attention! Ensure that the device is switched off during all actions and the
switching power supply is disconnected from the outlet!
1 Unpack the appliance, set it up and use the transport castors 7 to move it to the
place you want. To do this, lift slightly on the right-hand side. Remove battery
protection and protective foil from remote control 11.
2 Open evaporator compartment 3 and remove water tank 4.
3 Open water tank 4 and fill up to the MAX marker with cold water.
4 Close the water tank 4 securely.
5 Insert the water tank 4 into the water basin 6 and close the evaporator compart-
ment 3.
6 Adjust display 1 to the position you want (3 positions possible).
7 Adjust cable connector to the length you want by winding/unwinding in cable com-
partment 11. Note: Make sure the cable connector is firmly fitted into the appli-
ance!
Connect power plug to mains and switch appliance on using on/off switch 2 or
remote control 13.
i
It can take approx. 60 seconds for the appliance to start up and the red light
on the display to go out. You will be able to hear a noise (gurgling), which is not a
quality defect.
1 Display
2 On/off switch
3 Evaporator compartment
4 Water tank
5 VentWave DISC stack
6 Water tray
7 Transport castors
8 UVC lamp (pre-installed)
9 Cable compartment
10 Hygiene DISC (pre-installed)
11 Remote control
OVERVIEW
1
2
3
4
5
9
6
7 10
11
8
AW902
