18GBVenta LW62 WiFi
Attention! The coupling of the mains cable must be plugged rmly into the
device!
Please remove the protective foil for battery and
remote control.
Connect the power plug and
switch on the appliance at the
on/o switch 2 or with the remote control 11.
ATTENTION! Because of the lling process it may may take about 6 minutes for
the device to start.
Description of UVC lamp
The air washer features a built-in UVC lamp 8. The UVC lamp is designed for a
hygienically awless operation of the air washer and prevents the formation of
germs and bacteria in the water. It is active for 4 hours a day.
Set fan stage
ON/OFF
Connection to the water supply
A shut-o valve with a ¾” connecting thread is required for the connection
to the water supply.
∙ Connect the stainless steel tube to the shut-o valve with the straight
side. Make sure it is screwed in rmly.
∙ Fasten the stainless steel tube to the magnet valve on the lower side of
the device. Make sure it is screwed in rmly and sealed properly.
∙ Open the shut-o valve of the water supply carefully and check the enti-
re water system for leaks.
∙ Now connect the device to the electric power supply.
∙ Slide the device to the desired position. Make sure that the stainless
steel tube is not bent or damaged.
02 Inserting the fragrance: Open the fragrance compartment 6. Twist
open the fragrance cap and insert it into the fragrance holder 7. Insert
up to three fragrances into the fragrance holder 7. Close the fragrance
compartment 6.
03 The display 1 can be adjusted to three positions.
04 The power cable can be adjusted to the desired length by winding it up in
the cable compartment 9.
