Ventana BenchMark GX Quick Reference Guide
III. Load slides and reagents
21. Remove the reagent tray.
22. Open the slide doors
23. Press down on either corner of the top
door to release the latch, and then pull
the front door forward to open it.
24. Lift the top door up.
25. Manually rotate the slide carousel to the
desired position.
26. Place each slide on a slide heater pad
with the label facing up and outward,
making sure the slide is seated between
the posts.
21.
22.
24.
28.
31.
26.
32.
27.
27.
25.
25.
27. Close the top slide door.
28. Place the reagent dispensers on the
reagent tray.
29. Remove each dispenser cap and place it
on the cap holder.
30. Push the dispenser into the slot until it
clicks into place. (Avoid pressing down
on the top of the dispenser.)
31. Place the reagent tray on the reagent
carousel. Turn gently to make sure it is
seated securely.
32. Close the front slide door, making sure
thetabonthedoortsoverthebaseof
the reagent tray.
