Power must be isolated during installation and before maintenance to avoid injury by electric shock. The
specifications of cables must strictly match the requirements, otherwise it may cause performance fail-
ure and danger of electric shock or fire.
Power supply is AC220V/50HZ/1 Phase. Open the cover of electrical box, connect the 2 wires (L/N/) to
the terminals and connect the cable of the control panel to the board according to the wiring diagram,
and join the control panel to the cable.
We do not accept any liability for any problems caused by the user’s self and non-authorized re-
engineering to the electrical and control systems.
12
Electrical Installation
Model Capacitor Power Supply Control Panel Model
VENTING VHBQi-D015TFA
~D025TFA 1.5μF 450V AC
220-240V/1Ph/50Hz
Standard intelligent
Controller (HDK-10)
VENTING VHBQi-D035TFA
3μF 450V AC
VENTING VHBQi-D050TFA
3.5μF 450V AC
VENTING VHBQi-D065TFA
8μF 450V AC
VENTING VHBQi-D080TFA
8μF 450V AC
VENTING VHBQi-D100TFA
10μF 450V AC
VENTING VHBQi-D150TFA
8μF 450V AC
VENTING VHBQi-D200TFA
10μF 450V AC
Model
Spec. of power supply
cable
Spec. of normal controller
cable
VENTING VHBQi-D015TFA
2×1.5mm
2
2×0.5mm
2
VENTING VHBQi-D025TFA
VENTING VHBQi-D035TFA
VENTING VHBQi-D050TFA
VENTING VHBQi-D065TFA
VENTING VHBQi-D080TFA
VENTING VHBQi-D100TFA
VENTING VHBQi-D150TFA
VENTING VHBQi-D200TFA
