Installation and Operation Requirements - HES140
ENGLISH
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts
for your unit, please provide the model number and the serial number. We reserve the right to
change parts due to technology upgrades or availability. Contact an authorized dealer to obtain
any of these parts. Never use substitute materials. Use of non-approved parts can result in poor
performance and safety hazards.
# Item Description Qty
1 21622 13 7/16" X 6 3/4" X 1" VERMICULITE BAFFLE 2
2 PL66833 REAR SECONDARY AIR TUBE 1
3 PL66834 REAR CENTER SECONDARY AIR TUBE 1
4 PL66835 FRONT AND CENTER SECONDARY AIR TUBE 2
5 PL74288 AIR DEFLECTOR 1
6 30154 BLACK SCREW #10 X 5/8" QUADREX #2 TYPE A 24
7 SE74262 BACK HEAT SHIELD ASSEMBLY 1
8 29007 3 1/4'' X 9'' X 1 1/4'' REFRACTORY BRICK 4
9 29010 4 1/2" X 9" X 1 1/4" REFRACTORY BRICK 2
10 29015 4'' X 9'' X 1 1/4'' REFRACTORY BRICK 12
11 29000 4'' X 8'' X 1 1/4'' REFRACTORY BRICK 2
12 SE46264 VB00023 INSTRUCTION MANUAL KIT 1
13 SE74167 DOOR HINGE REPLACEMENT KIT 1
14 PL74293 DECORATIVE PANEL 2
15 SE74355 ASSEMBLY AIR CONTROL HATCH KIT 1
16 30734 COIL HANDLE 3/8" BLACK 1
17 PL74289 ASH TRAY 1
18 30507 BLACK TORX SCREW WITH FLAT HEAD TYPE F 1/4-20 X 3/4" 3
19 SE74272 HES 140 GLASS AND MOLDING KIT 1
20 SE53585 GLASS RETAINER KIT WITH SCREWS (12 PER KIT) 1
21 PL74353 GLASS FRAME 2
22 SE74254 11 1/4'' X 9 5/8'' GLASS WITH GASKET 1
23 AC06400 3/4" X 6' FLAT BLACK SELF-ADHESIVE GLASS GASKET 1
24 30101 SPRING TENSION PIN 5/32"Ø X 1 1/2"L 1
25 SE24352 VENTIS 1.4 DOOR WITH HANDLE AND GASKET 1
26 AC06500 SILICONE AND 5/8" X 8' BLACK DOOR GASKET KIT 1
27 SE70697 REPLACEMENT HANDLE WITH LATCH KIT 1
28 AC09185 DOOR LATCH KIT 1
29 AC07868 1/2" BLACK COIL HANDLE 1
30 SE74271 HES140 PEDESTAL ASSEMBLY 1
31 PL74268 BACK OF THE BASE 1
32 PL74354 DECORATIVE DASH 1
33 30536 LEVELING BOLT 1/4 - 20 X 1'' 4
34 30185 17/64" AA TYPE WASHER BLACK 4
35 30100 BLACK HEX NUT 1/4 - 20 (NON-OILED) 4
