Ventis HES140 - Stove Dimensions

Page 7
Installation and Operation Requirements - HES140
ENGLISH
2.3 Dimensions
2.3.1 Stove Dimensions
10"
254mm
20"
508mm
6 5/8"
170mm

6"
153mm
11"
280mm
OPTION
Figure 1: Top View
15 1/2"
394mm
8 1/4"
209mm
10 1/8"
256mm
30 1/4"
767mm
28 1/4"
716mm
29"
737mm
20 5/8"
524mm
22 3/4"
578mm
33 1/2"
850mm
OPTION
Figure 2: Front View Figure 3: Side View
