IMPORTANT:
The installation to the mains power supply may only be wired by a competent electrician. The
power supply cable must be selected in the ratio with power of the heater. When installing these
heaters, the standards and regulations in force in your country must be followed strictly adhered to.
Within the installation an electrical isolation automatic circuit breaker (not included) must be present,
to enable the installer to cut all power supply lines. Automatic circuit breaker must be selected
regarding power and nominal current (see the electrical rating plate on the heater casing top) of the
heater and should have characteristic B. Connect the heater to the mains power supply, check that
the voltage, frequency, power and current are the same as those indicated on the electrical rating
plate. The heater must be earthed.
We recommend install supply air temperature sensor in distance multiplied by the heater’s
diameter (3xD). For example: heater EKA diameter 200 mm, sensor’s installation distance will be:
3x200=600 mm.
Fig. 2. Mounting example EKA NV…
Fig. 3. Mounting example EKA NI…
