TIRE PRESSURE
Figure 46
Figure 48
D-6
SERVICE & MAINTENANCE
BRAKE ADJUSTMENT
A 6” diameter brake band is activated by the
3-position control selector. The brake holds only
when the lever is in the down position. If brake is
not holding sufficiently, tighten the 1/4” nut on the
brake linkage, located on the right side, just below
the dash (Figure 46). Turn the lock nut clockwise
several turns. Check if sufficient pressure is
applied for brake to hold. Adjust lock nut until the
brake hold is firm. If the brake adjustment is too
tight, it will be difficult to engage the control
selector into the park position.
Brake
Adjustment
Fuse Block
ELECTRICAL
Fuses and relays are conveniently located just
under the dash and accessible with the hood open
(Figure 48).
See wiring diagram. (Section B of Parts Manual)
NOTE: There is an inline fuse located at the
starter.
