7
EN
DELIVERY SET
Fan 1 pc.
Screws and dowels 4 pcs.
Plastic screwdriver (all fans with a timer) 1 pc.
User’s manual 1 pc.
Packing box 1 pc.
BRIEF DESCRIPTION
The unit described herein is an axial mixed-flow fan for supply or exhaust ventilation of premises.
The fans for 100, 125, 150, 160 mm air ducts have a two-speed motor and the fans for 250 and 315 mm have
a single-speed motor.
The units for 100, 125, 150, 160 air ducts are equipped with a two-speed motor, for 250 and 315 air ducts – with
a single-speed motor.
Ø D B H L
ТТ 100 96 167 190/221* 246
ТТ 125 123 167 190/221* 246
ТТ 125 S 123 223 250/279* 295
ТТ 150 146 223 250/279* 295
ТТ 160 158 233 250/279* 295
ТТ 250
247 287 323/340* 383
ТТ 315
310 362 408/424* 445
*TT XXX U/Un/U1/U1n/U2/U2n/P
