Vents VKPD - Technical Data

5
The unit is designed for application with the ambient temperature ranging from -20 °C up to +40 °C and relative humidity up to 80 %.
The fan is designed to remove smoke and air mixtures up to +400 °C for 120 minutes and for continuous operation at a temperature of the
transported medium up to +100 °C.
The unit is rated as a Class I electrical appliance.
Motor protection degree according to IEC 60034-5 – IP55.
The unit design is constantly being improved, thus some models may be slightly different from those described in this manual.
TECHNICAL DATA
Standard
size
Number of
poles
Voltage [V] at
50 Hz
Fan model
Installed motor
power [kW]
RPM [min
-1
]
250
2 1~230 VKPD-250-2E/0.37-500x300 0.37 2880
2 3~400 VKPD-250-2D/0.37-500x300 0.37 2880
2/4 3~400 VKPD-250-2/4D/0.37/0.1-500x300 0.37/0.1 2880/1440
280
2 1~230 VKPD-280-2E/0.55-600x300 0.55 2880
2 3~400 VKPD-280-2D/0.55-600x300 0.55 2880
2/4 3~400 VKPD-280-2/4D/0.55/0.1-600x300 0.55/0.1 2880/1440
315
2 1~230 VKPD-315-2E/1.1-600x350 1.1 2880
2 3~400 VKPD-315-2D/1.1-600x350 1.1 2880
2/4 3~400 VKPD-315-2/4D/1.1/0.25-600x350 1.1/0.25 2880/1440
355
4 1~230 VKPD-355-4E/0.37-700x400 0.37 1420
4 3~400 VKPD-355-4D/0.37-700x400 0.37 1420
4/6 3~400 VKPD-355-4/6D/0.55/0.1-700x400 0.55/0.1 1420/905
400
4 1~230 VKPD-400-4E/0.55-700x400 0.55 1420
4 3~400 VKPD-400-4D/0.55-700x400 0.55 1420
4/6 3~400 VKPD-400-4/6D/0.55/0.25-700x400 0.55/0.25 1420/905
450
4 1~230 VKPD-450-4E/0.75-800x500 0.75 1435
4 3~400 VKPD-450-4D/0.75-800x500 0.75 1435
4/6 3~400 VKPD-450-4/6D/0.8/0.2-800x500 0.8/0.2 1435/905
500
4 1~230 VKPD-500-4E/1.5-800x500 1.5 1430
4 3~400 VKPD-500-4D/1.5-800x500 1.5 1430
4/6 3~400 VKPD-500-4/6D/1.5/0.37-800x500 1.5/0.37 1430/920
560
4 1~230 VKPD-560-4E/3-900Х600 3 1435
4 3~400 VKPD-560-4D/3-900Х600 3 1435
4/6 3~400 VKPD-560-4/6D/2.8/0.7-900x600 2.8/0.7 1435/950
4/8 3~400 VKPD-560-4/8D/2.8/0.55-900x600 2.8/0.55 1435/710
630
4 3~400 VKPD-630-4D/4-1000x700 4 1445
4/6 3~400 VKPD-630-4/6D/3.8/1-1000x700 3.8/1 1445/950
4/8 3~400 VKPD-630-4/8D/3.8/0.75-1000x700 3.8/0.75 1445/720
710
4 3~400 VKPD-710-4D/7.5-1200x800 7.5 1455
4/6 3~400 VKPD-710-4/6D/7.5/2.2-1200x800 7.5/2.2 1455/960
4/8 3~400 VKPD-710-4/8D/7.5/1-1200x800 7.5/1 1455/720
