The electrical connections are terminated on the terminal block located inside the fan casing
in accordance with the Wiring Diagram and the terminal designations (Fig. 7).
The terminal designation diagram is given on a label inside the terminal box.
2
3 4
The steps for connecting the fan to power mains are given on Fig. 8.
L
N
X1
1
2
3
N
L
QF
PE
~230 V
50/60 Hz
4
РЕ
Figure 7
Figure 8
VP
