6
INSTALLATION AND OPERATION INSTRUCTIONS
The fan is installed between the floor slab and the suspended ceiling by means of
two mounting brackets. The distance between the bracket attachment point and the
suspended ceiling must be within 165 - 390 mm.
The fan installation steps are given in Fig. 5, 6.
The power is supplied via an external terminal box mounted to the fan casing.
WARNING: If unusual oscillating movement is observed, immediately stop using the
ceiling fan and contact the manufacturer, its service agent or suitably qualified persons!
The fan is to be installed so that the blades are more than 2.3 m above the floor!
Figure 4
Figure 3
