E - 7
Unit
CONTROL REFERENCE GUIDE
1) Open button
Open the disc door.
2) POWER ON/OFF switch
3) DC IN 12V jack
4) Disc Door
Close by pushing the disc door.
5) MONITOR 1 & 2 ports (output)
6) DIGITAL OUT jack
7) DVD AV OUT jack
8) Cursor (
, , , ) button
Use to highlight selections on a menu screen
and make adjustments to certain settings.
ENTER button
Confirm selections on a menu screen.
9) ZOOM button
Zoom into an image of a DVD.
AUDIO button
Select one of the audio soundtracks
programmed on a DVD or select the audio
output mode on a AUDIO CD.
MENU button
Open and close DVD's menu.
PREV button
Press PREV button to go back to previous
chapters/tracks. Press and hold PREV button
to begin fast scan. Four speeds are available.
NEXT button
Press NEXT button to advance to chapters /
tracks. Press and hold
NEXT button to begin
fast scan. Four speeds are available.
PAUSE/SETUP button
Press to pause playback of disc. Each time you
press the PAUSE button the picture advances
one frame. Press the PLAY
button to resume
playback.
In stop mode, open and close the SETUP menu
of the unit.
STOP button
Stop playing a disc.
PLAY button
Press to start or resume playback a disc.
10) AV IN / DVD switchs (MONITOR 1 & 2)
11) AV IN jack
12) Headphone jack
13) VOLUME control
Adjust the volume.
14) STANDBY indicator
The indicator will illuminate when the unit is in
standby mode.
15) POWER ON indicator
When the POWER ON/OFF is switched to ON
position, the light will illuminate.
16) Remote sensor
Receives the remote control unit signals.
