MONITOR
Note:
When the monitor is connected to the main unit(DVD Player) with the EZ VIEW cable, DC 12V power, Audio/
Video and IR signals will all be supplied through the EZ VIEW cable to the connected monitor. So there is no
need for another power source to be connected to the DC 12V jack on the right side of the monitor.
1
To DC IN jack
AC ADAPTOR
2
AC POWER CORD
3
To AC outlet
To AC adaptor
EZ VIEW CABLE
CORRECT CONNECTION
INCORRECT CONNECTION
AC ADAPTOR
1
To DC IN 12V jack
2
To the 12V car socket
CAR POWER
ADAPTOR
OR
1
To DC IN
12V jack
OR
1
To DC IN jack
CAR POWER
ADAPTOR
2
To the 12v car socket
EZ VIEW CABLE
2
AC POWER CORD
3
To AC outlet
To AC adaptor
