Page 8 BVI 3000 Operator’s Manual
Scanhead
The scanhead transmits and receives
ultrasound, automatically moving its internal
transducer 360º to scan twelve planes and
produce a three-dimensional image of the
urinary bladder. The scanhead is connected to
the control unit by means of a cable.
Control Unit
The control unit provides all operating controls
for the scanning procedure by means of six
soft keys. The measured bladder volume and a
target-shaped aiming icon are clearly displayed
on the LCD screen, helping the operator to
achieve accurate measurement results.
Batteries & Charger
Two NiMH rechargeable batteries are included with the BladderScan BVI 3000. One battery can be
recharged in the battery charger while the other is being used to power the BVI 3000. This ensures that
there is no instrument downtime. The charger brings the battery to a full charge in 6 hours or less.
(See picture and instructions for charging the battery on the following page.)
The BladderScan BVI 3000 consists of 4 main components: The Scanhead, Control Unit, Rechargeable
Battery, and the Battery Charger.
Description of the BladderScan
®
BVI 3000
Connecting the
Scanhead
Connect the scanhead to the input socket at the back of the instrument
by aligning the tabs on the scanhead plug with the matching slots on the
instrument socket. Press the plug straight in until you hear a click.
To remove the plug, grasp the black plastic ring and pull straight out. Do
not twist.
Preparation For Use
