DEVICE SETUP
Charging Base
16 T650M INSTALLATION GUIDE
To Connect the
Terminal Power
Supply
Insert the USB-C to the T650m and USB-A port to the power supply or Desktop.
Figure 5 T650m Power Supply Connection
Charging Base
The T650m is designed to work with a charging base. The user can alternatively
place the terminal on the available charger base to conveniently charge the
battery and prevent the discharge to less than 10%.
Figure 6 T650m Docking with Charging Base
Charging the
Battery
After unpacking your T650m device, connect the power pack to the unit for eight
hours or until fully charged. Refer to the Using the Battery section for more details.
To protect against possible damage caused by lightning strikes and electrical
surges, consider installing a power surge protector.
