8
9B9BMounting the Device
19B19BHorizontal Mounting
Place the device on a smooth surface with good ventilation. Place it at least 4 inches away
from other objects.
20B20BVertical Mounting
Fix two wall screws into the wall with the screw heads extending approximately 0.1 inches
from the surface of the wall. The diameter of a screw head should be between 0.22 inches
and 0.28 inches. The distance between two screws should be 3.98 inches. Align the
mounting brackets with the screws, push the device towards the wall, and connect the
brackets with the screws ensuring that the device is stable.
